12v Metal Silver 150psi Air Ride Suspension Compressor Stainless Load Hose For Land Rover

12v Metal Silver 150psi Air Ride Suspension Compressor Stainless Load Hose For Land Rover

    • 12v Metal Silver 150psi Air Ride Suspension Compressor Stainless Load Hose For Land Rover
    • 12v Metal Silver 150psi Air Ride Suspension Compressor Stainless Load Hose For Land Rover
    • 12v Metal Silver 150psi Air Ride Suspension Compressor Stainless Load Hose For Land Rover
  • 12v Metal Silver 150psi Air Ride Suspension Compressor Stainless Load Hose For Land Rover

    Product Details:

    Place of Origin: CHINA
    Brand Name: N / M
    Certification: CE&ROHS
    Model Number: YF6463R

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Depands On Qty
    Packaging Details: Color box or Blister with card and Strong Carton
    Delivery Time: 30 days after receiving 30% deposit
    Payment Terms: L/C, T/T
    Supply Ability: 4000pcs 30 days
    Contact Now
    Detailed Product Description
    Brand: OEM Voltage: 150psi
    Power: Heavy Duty Popularity: Hot
    Current: 23 Amps Moisture Resistant: IP 54
    Warranty: 12 Months Delivery: 20-30 Days After Received Your Deposit

    Yurui 6463R Black And Silver 150psi Air Ride Suspension Compressor Stainless Load Hose







    Description



    YF6463R is an installation type air suspension pump, which specifically applies to the professional equipment where needs fast-speed and extensive air, such as tire inflation, agriculture seeder, armaria, extracting oil and even in aircraft manufacturing corporation. Always integrated into on-board air system.



    Commonly used must with air tanks in car tuning like off-road cars.The compressor is consist with an on-off pressure button. It automatically turns on and off when the pressure reaches the certain level. The part, air filter can be used in a remote situation when the environment changes. The compressor is furnished with a thermal overload protector which will turn off the unit if overheated.





    Used with



    Air tanks in different sizes

    Pneumatic system

    Air horns





    Our Advantages



    1 . One year warranty

    2 . Competitive price than other manufactures

    3 . Portable to carry with

    4 . Fast inflation and low noise

    5 . Can be pumped more than 20 , 000 times

    6 . Anti-dust and explosion-proof

    7 . Water resistant IP 54





    To which places you have exported?



    America, Europe, South Asia, and so on.

    How about your delivery time?

    20-30 working days after we received your deposit.





    How to guarantee your after sales service?



    1. We check every item’s quality during the production

    2. Recheck the products before shipment to ensure our packaging in good condition.

    3. Track and receive feedback from our customer.




    SPECIFICATION



    2.04CFM 150PSI



    • 12 Volt

    • Duty Cycle: 30% @ 100 PSI

    • Max. Working Pressure: 150 PSI

    • 12V Max. Amp Draw: 23 Amps

    • Net Weight: 7.72 lbs

    9.45"Lx4"Wx6.45"H





    PERFORMANCE DATA

    PSI 0 40 90 150
    AMPS 13 19 22 21
    CFM 2.04 1.48 1.2 0.77
    LPM 58 42 34 22
    BAR 0 3 6 10



    RECOMMENDED TANK12v Metal Silver 150psi Air Ride Suspension Compressor Stainless Load Hose For Land Rover

    TANK FILL DATA



    2.0 Gallon Tank

    0 to 150 psi 2 min 15 sec

    120 to 150 psi 45sec




    ♦ DUTY CYCLE REFERENCE CHART



    Duty Cycle: 100PSI @ 72◦F Max. Run Time / Min. Rest Time



    Duty cycle refers to the amount of time compressor can be operated in a given time period at 100PSI and a standard ambient temperature of 72◦F. Duty cycle is commonly expressed in percentage format as: Compressor on time / (on time + off time)= Duty Cycle%

    9% Duty Cycle 3 Min. On / 30 Min. Off
    10% Duty Cycle 3 Min. On / 30 Min. Off
    15% Duty Cycle 6 Min. On / 30 Min. Off
    20% Duty Cycle 8 Min. On / 30 Min. Off
    25% Duty Cycle 10 Min. On / 30 Min. Off
    30% Duty Cycle 13 Min. On / 30 Min. Off
    33% Duty Cycle 15 Min. On / 30 Min. Off
    40% Duty Cycle 20 Min. On / 30 Min. Off
    100% Duty Cycle Continous Duty @ 100PSI @ 72◦F





    12v Metal Silver 150psi Air Ride Suspension Compressor Stainless Load Hose For Land Rover
