Durable Heavy Duty OffRoad Air Ride Suspension Compressor DC12v Chrome Steel

Portable Off-Road DC12V Air Suspension Pump

► Description

    YF6456R is an installation type air suspension pump, which specifically applies to the professional equipment where needs fast-speed and extensive air, such as tire inflation, agriculture seeder, armaria, extracting oil and even in aircraft manufacturing corporation.

    It is commonly used with air tanks in car tuning like off-road cars.The compressor is consist with an on-off pressure button. It will automatically turn on and off when the pressure reaches the certain level. The part, air filter can be used in a remote situation.  One thing needed to bring out is that this product is very popular in the USA and Brazil.

► Used with

1. Performance and Custom Vehicles

   • Sports Cars: Performance vehicles use air suspension to adjust ride height for better aerodynamics and handling. The compressor provides the necessary adjustments for optimal performance.
   • Custom and Modified Cars: Enthusiasts use air suspension for aesthetic and functional modifications, such as lowering the vehicle for shows or raising it for improved drivability on uneven roads.

2. Off-Road and Recreational Vehicles

   • Off-Road Trucks and SUVs: Air suspension systems allow for adjustable ride height, providing better ground clearance when off-roading and a smoother ride on paved roads. The compressor adapts the suspension based on the terrain.
   • RVs and Camper Vans: Recreational vehicles use air suspension to manage varying weights and improve ride comfort during long journeys. The compressor adjusts the suspension to handle different road conditions and loads.

• Air tanks in different sizes

• Pneumatic system

• Air horns

► Why choose us?

1. We are the professional manufacturers with 15 years experience.

2. The boss is a 20-year experienced engineer to give the promise of great quality.

3. We listen. We listen every customer’s voice to meet the request.

4. We, every worker is passionate, hard-working and careful of the inspection in every step.

5. 24-hour available sales are standby to solve your questions.

► SPECIFICATION

    1.8CFM      200PSI

• 12 Volt

• Duty Cycle: 100% @ 100 PSI

• Duty Cycle: 50% @ 200 PSI

• Max. Working Pressure: 200 PSI

• 12V Max. Amp Draw: 23 Amps

• 3/8"NPT Inlet port

• Net Weight: 11 lbs

11"Lx4"Wx6.55"H

► PERFORMANCE DATA

► RECOMMENDED TANK

    TANK FILL DATA

2.5 Gallon Tank

0      to 200 psi   4 min 58 sec

150  to 200 psi   1 min 50 sec

5.0 Gallon Tank

0      to 200 psi   10 min 10 sec

150  to 200 psi     2 min 50 sec

♦ DUTY CYCLE REFERENCE CHART
