Portable 12V Air Ride Suspension Compressor 100 PSI for Offboard Car
  • Portable 12V Air Ride Suspension Compressor 100 PSI for Offboard Car
  • Portable 12V Air Ride Suspension Compressor 100 PSI for Offboard Car
  • Portable 12V Air Ride Suspension Compressor 100 PSI for Offboard Car

Portable 12V Air Ride Suspension Compressor 100 PSI for Offboard Car

Place of Origin CHINA
Brand Name YURUI
Certification CE&ROHS
Model Number YF6463R
Product Details
Water Resistant:
IP54
Color:
Black And Silver
Material:
Steel
Original:
China
Voltage:
12V
Power:
Heavy Duty
Application:
On-board Air System, Car Tuning, Off-board Car
Recommended Parts:
Air Tank
High Light:

air ride pump

,

air bag suspension pump

Payment & Shipping Terms
Minimum Order Quantity
Negotiation
Price
Consultation
Packaging Details
Color box with foam and strong carton
Delivery Time
One month after receiving 30% deposit
Payment Terms
T/T, L/C
Supply Ability
4000pcs 30 days
Product Description

Chrome Black Silver Portable 12V Air RIde Suspension Compressor for Offboard Car





► Description



YF6463R is an installation type air suspension pump, which specifically applies to the professional equipment where needs fast-speed and extensive air, such as tire inflation, agriculture seeder, armaria, extracting oil and even in aircraft manufacturing corporation. Always integrated into on-board air system.

Commonly used must with air tanks in car tuning like off-road cars.The compressor is consist with an on-off pressure button. It automatically turns on and off when the pressure reaches the certain level. The part, air filter can be used in a remote situation when the environment changes. The compressor is furnished with a thermal overload protector which will turn off the unit if overheated.





► Used with



Air tanks in different sizes

Pneumatic system

Air horns





► Our Advantages



1 . One year warranty

2 . Competitive price than other manufactures

3 . Portable to carry with

4 . Fast inflation and low noise

5 . Can be pumped more than 20 , 000 times

6 . Anti-dust

7 . Water resistant IP 54






► SPECIFICATION



2.04CFM 150PSI



• 12 Volt

• Duty Cycle: 30% @ 100 PSI

• Max. Working Pressure: 150 PSI

• 12V Max. Amp Draw: 23 Amps

• Net Weight: 7.72 lbs

9.45"Lx4"Wx6.45"H





To which places you have exported?



America, Europe, South Asia, and so on.

How about your delivery time?

20-30 working days after we received your deposit.





► PERFORMANCE DATA

PSI 0 40 90 150
AMPS 13 19 22 21
CFM 2.04 1.48 1.2 0.77
LPM 58 42 34 22
BAR 0 3 6 10



RECOMMENDED TANKPortable 12V Air Ride Suspension Compressor 100 PSI for Offboard Car 0

TANK FILL DATA



2.0 Gallon Tank

0        to   150 psi  2 min 15 sec

120    to   150 psi            45sec




♦ DUTY CYCLE REFERENCE CHART



Duty Cycle: 100PSI @ 72F Max. Run Time / Min. Rest Time



Duty cycle refers to the amount of time compressor can be operated in a given time period at 100PSI and a standard ambient temperature of 72F. Duty cycle is commonly expressed in percentage format as: Compressor on time / (on time + off time)= Duty Cycle%

9% Duty Cycle 3 Min. On / 30 Min. Off
10% Duty Cycle 3 Min. On / 30 Min. Off
15% Duty Cycle 6 Min. On / 30 Min. Off
20% Duty Cycle 8 Min. On / 30 Min. Off
25% Duty Cycle 10 Min. On / 30 Min. Off
30% Duty Cycle 13 Min. On / 30 Min. Off
33% Duty Cycle 15 Min. On / 30 Min. Off
40% Duty Cycle 20 Min. On / 30 Min. Off
100% Duty Cycle Continous Duty @ 100PSI @ 72F




Portable 12V Air Ride Suspension Compressor 100 PSI for Offboard Car 1
