Silver Compressor 1.0Gallon Tank Quarter Duty Cycle Onboard Air System For Cars
► Description
YF7003 is an installation type air suspension pump with tanks, which specifically applies to the professional equipment where needs fast-speed and extensive air, such as tire inflation, agriculture seeder, armaria, extracting oil and even in aircraft manufacturing corporation. Always integrated into on-board air system.
Commonly used must with air tanks in car tuning like off-road cars.The compressor is consist with an on-off pressure button. It automatically turns on and off when the pressure reaches the certain level. The part, air filter can be used in a remote situation when the environment changes. The compressor is furnished with a thermal overload protector which will turn off the unit if overheated.
► Our Advantages
1 . Good service and after-sale service
2 . Competitive price than other manufactures
3 . Portable to carry with
4 . Fast inflation and low noise
5 . Can be pumped more than 20 , 000 times
6 . Anti-dust and explosion-proof
7. Excellent quality
► PERFORMANCE DATA
| PSI |
0 |
40 |
90 |
140
|
| AMPS |
11 |
17 |
20 |
18 |
| CFM |
1.9 |
1.5 |
1.0 |
0.74 |
| LPM |
53 |
42 |
28 |
21 |
| BAR |
0 |
3 |
6 |
10 |
►TANK FILL DATA
1.0 Gallon Tank
0 to 140 psi 1 min 28 sec
100 to 140 psi 30 sec
►DUTY CYCLE REFERENCE CHART
| Duty Cycle: 100PSI @ 72◦F |
Max. Run Time / Min. Rest Time |
Duty cycle refers to the amount of time compressor can be operated in a given time period at 100PSI and a standard ambient temperature of 72◦F. Duty cycle is commonly expressed in percentage format as: Compressor on time / (on time + off time)= Duty Cycle%
|
| 9% Duty Cycle |
3 Min. On / 30 Min. Off |
| 10% Duty Cycle |
3 Min. On / 30 Min. Off |
| 15% Duty Cycle |
6 Min. On / 30 Min. Off |
| 20% Duty Cycle |
8 Min. On / 30 Min. Off |
| 25% Duty Cycle |
10 Min. On / 30 Min. Off |
| 30% Duty Cycle |
13 Min. On / 30 Min. Off |
| 33% Duty Cycle |
15 Min. On / 30 Min. Off |
| 40% Duty Cycle |
20 Min. On / 30 Min. Off |
| 100% Duty Cycle |
Continous Duty @ 100PSI @ 72◦F |
